Production 3D Printer
The Fortus 450mc is a Workhorse 3D printer that performs with reliability, repeatability, and durability unmatched in the industry.
Take designs from virtual to real in hours, not weeks. From functional prototypes with exacting tolerances, to manufacturing tools that perform under pressure, the Fortus 450mc 3D printer sets a high bar for speed, performance and accuracy.
Fortus 450mc 3D Printer Features
Large Build Size
The Fortus machine has a large build size at 406 x 355 x 406 mm (16 x 14 x 16 in).
Easy Installation and Operation
The Fortus 450mc features an all-new touchscreen interface for straightforward operation and maintenance.
Fast Production Runs
The Fortus 380/450mc can build complex parts faster than it’s predecessors, and offers the same fast build time as other production machines.
Multiple FDM Production Materials
Delivers models in ABS-ESD7, ABS-M30, ABS-M30i, Antero 800NA, ASA, FDM Nylon12, FDM Nylon12CF, PC, PC-ABS, PC-ISO, ULTEM 9085, ULTEM 1010, and ST-130 production-grade thermoplastics used in real manufacturing applications.
Fortus 450mc Benefits
Production Parts & Tooling
Printing a low-volume production run with a Fortus machines can maximize sales opportunities while minimizing cost and lead time because there’s no minimum quantity requirement. Plus, part complexity doesn’t add time or cost, so production can begin as soon as the CAD files are sent to the 3D production system.
The Fortus systems provide a fast and accurate means of producing tooling. The efficiency of the FDM 3D Printing process makes it practical to optimize tooling design.
Easy to operate & safe to use
Compared to other additive fabrication systems, Fortus 3D Production Systems are easy to operate and maintain as there are no messy powders to handle and contain. They’re so simple, an operator can be trained to operate a Fortus system in less than 30 minutes.
You can install a Fortus 3D Production System just about anywhere. No special venting is required because Fortus systems produce no noxious fumes, chemicals or waste.
Materials available for the Fortus 450mc
ABS-ESD7
ABS-ESD7™ is an ABS thermoplastic with static dissipative properties for applications where a static charge can damage products, impair their performance or cause an explosion.
ABS-M30
ABS-M30™ is up to 25 to 70 percent stronger than standard ABS and is an ideal material for conceptual modeling, functional prototyping, manufacturing tools and production parts.
ABS-M30i
ABS-M30i is a high strength material well suited for the medical, pharmaceutical and food packaging industries, parts are biocompatible (ISO 10993 USP Class VI)
Antero 800NA
Antero 800NA is a PEKK-based FDM 3D printing thermoplastic. It delivers excellent strength, toughness and wear-resistant properties of PEKK material.
ASA
ASA 3D printing material is ideal for parts that are going to be used outdoors. The printed parts are consistently high-quality, with exceptional UV stability.
FDM Nylon 12
FDM Nylon 12 material is ideal for repetitive snap fits, high fatigue resistance, strong chemical resistance and press (friction) fit inserts.
FDM Nylon 12CF (Carbon Fiber)
%title% material is ideal for repetitive snap fits, high fatigue resistance, strong chemical resistance and press (friction) fit inserts.
PC (Polycarbonate)
PC 3D printing material offers accuracy, durability and stability, creating strong parts that withstand functional testing.
PC-ABS
PC-ABS material is one of the most widely used industrial thermoplastics. PC-ABS offers superior strength and heat resistance of PC and the flexibility of ABS.
PC-ISO
PC-ISO (polycarbonate-ISO), an industrial thermoplastic, which in its raw state, is biocompatible (ISO 10993 USP Class VI) and can be gamma or EtO sterilized.
ULTEM 1010
ULTEM 1010 resin is a high-performance FDM® thermoplastic that offers excellent strength, thermal stability and the ability to withstand steam autoclaving.
ULTEM 9085
ULTEM 9085 resin is a flame-retardant high-performance thermoplastic for digital manufacturing and rapid prototyping.
Fortus 450mc Specifications
| Feature | Fortus 450mc Specification |
|---|---|
| Material delivery | Two bays each for material and support canisters Auto changeover between canisters |
| Build Envelope | 406 x 355 x 406 mm (16 x 14 x 16 in.) |
| Layer thickness | 0.254 mm (0.010 in.) or 0.330 mm (0.013 in) |
| Software | All Fortus systems include Insight™ and Control Center™ job processing and management software. Compatible with GrabCAD Print for use with job reports, scheduling and remote monitoring. |
| Workstation compatibility | Windows OS |
| Size and weight | 129.5 cm x 90.2 cm x 198.4 cm (51 x 35.5 x 78.1 in.) 601 kg (1325 lbs.) |
| Power requirements | 208VAC 3 phase, 50/60 Hz, consumes 18 Amps |
| Regulatory compliance | CE |
| Achievable Accuracy | Parts are produced within an accuracy of ± .127 mm (± .005 in.) or ± .0015 mm/mm (± .0015 in/in), whichever is greater). Z part accuracy includes an additional tolerance of -0.000/+slice height. Note: Accuracy is geometry dependent. Achievable accuracy specification derived from statistical data at 95% dimensional yield. |
| Material | Layer Thickness | Support Structure | Colors | |||
|---|---|---|---|---|---|---|
| 0.330 mm (0.013 in.) | 0.254 mm (0.010 in.) | 0.178 mm (0.007 in.) | 0.127 mm (0.005 in.) | |||
| ABS-ESD7 | ⬤ | ⬤ | Soluble | Black | ||
| ABS-M30 | ⬤ | ⬤ | ⬤ | ⬤ | Soluble | Ivory, White, Black, Red, Blue, Dark Gray |
| ABS-M30i | ⬤ | ⬤ | ⬤ | ⬤ | Soluble | Ivory |
| Antero 800NA | ⬤ | Breakaway | Natural | |||
| ASA | ⬤ | ⬤ | ⬤ | ⬤ | Soluble | Black, Dark Blue, Dark Gray, Green, Light Gray, Yellow, White, Orange, Ivory, Red |
| FDM Nylon 12 | ⬤ | ⬤ | ⬤ | Soluble | Black | |
| FDM Nylon 12CF | ⬤ | Soluble | Black | |||
| PC | ⬤ | ⬤ | ⬤ | ⬤ | Breakaway, Soluble | White |
| PC-ABS | ⬤ | ⬤ | ⬤ | ⬤ | Soluble | Black |
| PC-ISO | ⬤ | ⬤ | ⬤ | Breakaway | Translucent Natural, White | |
| ULTEM® 9085 resin | ⬤ | ⬤ | Breakaway | Tan, Black | ||
| ULTEM 1010 resin | ⬤ | ⬤ | Breakaway | Natural | ||
| ST-130 | Only available in 0.330 mm (0.013 in.) | Breakaway | Tan | |||
Industries
Stratasys 3D Printers are used in a wide variety of industry applications
Reverse Engineering
- Product design
- Customization
- 3D documentation
Industrial design and manufacturing
- Reverse engineering
- Quality control
- Rapid prototyping
- Aerospace
Medical and Life Sciences
- Orthopedics
- Prosthetics
- Plastic surgery
- Custom wheelchairs
Science and education
- Research
- Training
- Online museums
Art and design
- Heritage preservation
- Architecture
- CGI
- Fashion
Example Parts
Example Fortus 450mc prototypes and production parts in a wide range of materials and colors. Pick on the images below to enlarge:
Fused Deposition Modeling (FDM) Technology
Advantages of parts built with a Stratasys Fortus 450mc Machine
Tough long-lasting parts
High-performance thermoplastics combined with precision extrusion processes let us build strong, long-lasting and dimensionally stable parts;
TriMech production grade FDM solutions provide clients with the best accuracy, repeatability, and material selection of any 3D printing technology.
Used commonly in aerospace, automotive and transportation, manufacturing, and more, this process is helping clients do more, do it better, and do it for less.
Meet production demands
TriMech FDM production systems are as versatile and durable as the parts they produce.
With the largest full-convection build envelopes and material capacities in their class, we can provide longer, uninterrupted build times, bigger parts and higher quantities than other additive manufacturing service providers.
In combination with our material portfolio, we are challenging the limits of what can be done with FDM technology.
Gain new possibilities
TriMech’s FDM specialists will help to streamline your business processes from design through manufacturing, eliminating the need for physical inventories and moving beyond the limitations of traditional manufacturing, whilst offering unparalleled efficiency, design freedom, and production agility.
Leverage the best solution on the market without the capital expense of in-house equipment: we deliver a tailored service, combining 20+ years of experience with industry-leading FDM technologies. Regardless of industry, we’ll help optimize timelines, costs, and approach.
